5 axis CNC machining centre
EIMA
-
5 axis simultaneous operations
-
x/y/z working area: 10000 mm x 5000 mm x 2000 mm
-
Siemens 840D control
-
24000 rpm main spindle
Company Infrastructure.
Infrastructure is the foundation of any company; it’s the basic structure that all companies are built on.
4 axis CNC machining centre
Maple
-
3+1 indexed operations
-
x/y/z: working area: 1050 mm x 550 mm x 500 mm
-
Siemens 828D control
-
10000 rpm main spindle
S45 CNC lathe
EMCO
-
2 axis, live tooling and C-axis
-
max diameter: 220 mm
-
max length: 310 mm
-
Siemens 828D control
-
6300 rpm main spindle
-
5000 rpm live tooling
CNC cutter centre
ZÜND G3
-
x/y working area: 2500 mm x 1800 mm
-
conveyor for continuous cutting
-
cutting, kiss cut, sealing, routing
-
1 kW, 60.000 rpm routing spindle
Autoclave
-
working diameter: 1050 mm
-
working length: 2000 mm
-
max pressure: 8 bar
-
max temperature: 180 C
-
microprocessor temperature control and data logging
Oven
-
working area: 7500 m x 2000 mm x 2200 mm
-
max temperature: 180 C
-
microprocessor temperature control and data logging
Laser engraver
- Working area: 400mm x 300mm x 800mm
Pressmould
-
working area: 450 mm x 250 mm
-
max temperature: 200C
-
max pressure: 200 bar
-
microprocessor temperature control and data logging
Ultimaker S5, 3D printers
-
working area: 330 mm x 240 mm x 300 mm
Software
- 3D CAD: licenses of all common 3D CAD software packages to provide smooth exchange of data with customer software infrastructure
- CAM: Hexagon Edgecam with all available features allowing 5 axis simultaneous toolpath generation
- Structural analysis: in-house developed numerical integration tools for structural design, validation through FEM (Siemens Femap)
- Fluid dynamics: thermal and aerodynamic analysis through CFD
- Control systems design and analysis: Matlab and Matlab SimuLink
